| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Min. Illumination |
0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
No |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 30°, tilt: 0° to 75°, rotate: 0° to 355° |
| Focal Length & FOV |
4 mm: horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91°; 6 mm: horizontal FOV 50°, vertical FOV 27°, diagonal FOV 59° |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| Max. Resolution |
1920 × 1080 |
| Main Stream |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240); 60Hz: 30fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) |
| Third Stream |
no |
| Video Compression |
Main Stream: H.265/H.264, Sub-Stream: H.265/H.264 |
| Video Bit Rate |
256 Kbps to 8 Mbps |
| H.264 Type |
BaseLine Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Audio Compression |
G.711/G.726/AAC |
| Audio Bit Rate |
64Kbps |
| Audio Sampling Rate |
16 kHz |
| Environment Noise Filtering |
Yes |
| Network Protocols |
TCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SNMP, QoS, FTP，SMTP，HTTPS |
| Simultaneous Live View |
Up to 8 channels |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
| Network Storage |
microSD/SDHC/SDXC card (up to 128 GB), |
| Client |
No |
| Web Browser |
Plug-in required live view: IE10; |
| Image Settings |
Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day/Night/Auto/Schedule |
| Image Enhancement |
BLC, 3D DNR, |
| DNR |
3D DNR |
| Ethernet Interface |
Without -M: 1 RJ45 10M/100M self-adaptive Ethernet port; -M: 1 four-core M12 aviation plug |
| On-Board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 128 GB |
| Audio |
1 built-in mic, mono sound |
| Alarm |
No |
| Reset Key |
Yes |
| Basic Event |
Motion detection, video tampering alarm |
| Smart Event |
No |
| Linkage |
Upload to FTP, notify monitoring center, send email, trigger recording |
| Camera Dimension |
Camera：99.3 × 96.7 × 52.8 mm (3.9″ × 3.8″ × 2.1″); With package：252 × 160 × 95mm (9.9″ × 6.3″ × 3.7″) |
| Camera Weight |
Camera: Approx. 430 g (0.9 lb.); With package: 780 g (1.7 lb.) |
| Startup And Operating Conditions |
-30 °C to 75 °C (-22 °F to 167°F), humidity less than 95% or less (non-condensing) |
| General Function |
Anti-flicker, heartbeat, mirror, |
| Power Supply |
-ID: 9-36V, Ø5.5 mm coaxial power plug; -IM/ND: PoE (802.3af, 36 V to 57 V) |
