| Certificate Mark |
ExdⅡC T6 Gb/ Ex tD A21 IP68 T80℃ |
| Certificate No |
CNEx18.3765X |
| Standards |
Q/320412 ZAF046-2018 |
| Mechanical Housing |
Stainless steel 304 or 316L |
| IP |
IP68 |
| Cable thread hole |
1pcs G3/4 or NPT3/4 or M25*1.5 |
| Wiper |
yes |
| Electrical Voltage |
AC85V～AC265V or DC24Vor AC24V |
| Power |
50W /70W (with thermostat) |
| Ambient temperature |
-25 to +60℃ |
| Air pressure |
80Kpa to 106Kpa |
| Relative Humidity |
≦95% (no condensation) |
| Communication |
support analog video output |
| 485 Communication |
Support Pelco-D, Pelco-P |
| Communicate Rate |
2400 to 19200bps |
| Pan & Tilt |
Horizontal 360° |
| Horizontal speed |
0.1-45°/s |
| Vertical |
-90 to +90° |
| Cruise Scan |
Support |
| Keep watch |
Support |
| Preset |
64/128/255/300 |
| Resume function |
Support |
| Auto Cruise |
Support |
| Auto Pattern |
Support |
| Auto Scan |
Support |
| Alarm Input |
2-channel/ 7-channel |
| Alarm Output |
1-channel, action with alarm |
| Intelligent Alarm |
Audio detective, move detective, video shield, network interrupt, IP address conflict, storage full, storage error, illegal access |
| Audio Input |
Audio input (LINE input, MIC input), audio peak:2-2.4Vp-p,output impedance: 1KΩ+10% |
| Audio Output |
Line-level impedance 600Ω |
| Network Interface |
1pcs of RJ45, support 10M/100M/1000M |
| Video Compression |
H.264 main profile / MJPEG |
| Audio Compression |
G.722.1/ G.711-a law/ G7.11-u law/MP2L2/G.726 |
| Voice Intercom |
Support |
| Stream |
Support three streams |
| Internet Protocol |
IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE |
| Time Display |
Support |
| Standard |
ONVIF, CGI, GB/T28181, PISA |
| IE browser |
Support IE7 or above, Google, Firefox, Apple |
| Security |
Password protection, Multiple access control |
| Image Sensor |
1/2.8" interline-transfer CCD |
| Effective pixel |
1.3MP, 2MP, 3MP |
| Min. Illumination |
Color 0.05Lux B/W: 0.01Lux |
| Day&night |
Auto/ Color/ BW |
| S/N ratio |
＞52dB（AGC off） |
| Gain |
off/ lower/ higher |
| White Balance |
Auto/ Manual/ Auto tracking white balance/ indoor/outdoor/ Sodium Lamp/ Fluorescent Lamp |
| 3D DNR |
Support |
| BLC |
ON/OFF |
| Image setting |
Mirror, Saturation, Brightness, Contrast, Sharpness adjustable |
| Optical zoom |
20X / 30X |
| Cable |
integrated cable |
| Size |
316*258*358mm |
| Weight |
23kg |
| Mounted |
wall, pole |
| Wall bracket |
ZAZ6XXB |
