| Power Source |
230 V AC, 50/60 Hz |
| Power Consumption |
240 W max. |
| Applicable Battery |
Panasonic LC-X1265PG/APG (65 Ah) |
| Charging Method |
Trickle charging |
| Charging Current |
5 A max. |
| Charging Output Voltage |
27.3 V ±0.3 V (at 25 ℃ (77 ゜F)) / Temperature correction coefficient: -40 mV/℃ |
| Power Supply Input |
6 M4 screw terminal, distance between barriers: 11 mm (0.43") |
| DC Power Output |
6 (25 A max. each) M4 screw terminal, distance between barriers: 11 mm (0.43") |
| Control Connector |
RJ45 female connector for connecting the VX-2000SF Surveillance Frame. Twisted-pair straight cable (TIA/EIA-568A standard) / Type of control signal: Battery check, AC power status, DC power status, charging circuit failure, and battery failure |
| Battery Connection |
1 pair of positive and negative terminals / Applicable cable diameter: AWG 6 - AWG 0 (1/0) (Line resistance within 4 mΩ/total) / 2 / Cross sectional area: 16 - 50 mm |
| Operating Temperature |
0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Finish |
Panel: Surface-treated steel plate, black, 30 % gloss, paint |
| Dimensions |
482 (W) × 88.4 (H) × 377.6 (D) mm (18.98" × 3.48" × 14.87") |
| Weight |
10.5 kg (23.15 lb) |
| Accessory |
Rack mounting screw …4, Fiber washer …4, Blade fuse (40 A) …3, Fuse (T3.15A L) …1, Power cord (2 m (6.56 ft)) …1, Insulating sheet …1, Attention label (German) …1, Fastener hook …4, Fastener loop …4 / Sticker (Declaration of compliance) …1, Thermal insulating sheet …1 |
| Fuse Rating |
Blade fuse (40 A), Blade fuse (7.5 A), Fuse (T3.15A) |
| Internal Resistance |
Maximum internal resistance of the battery and its associated circuitry, Ri max: 50 mΩ |
| Current Specification |
Maximum output current draw from the battery: 43.5 A, Rated maximum continuous output current, I max a: 43.5 A / Rated maximum short duration output current, I max b: 43.5 A / Rated minimum output current, I min: 0 A |
| Cable Specification |
Recommended cable parameter for DS-SF Link: Twisted-pair straight cable (TIA/EIA-568A standard) |
