TOA VP-1241 Power Amplifier 240W (301H version)
- All products
- PABGM
- TOA VP-1241 Power Amplifier 240W (301H version)
- PABGM
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Product Specification
| Power Source | AC: 230 V AC, 50/60 Hz / DC: 24 V DC |
| Power Consumption | AC: 537 W (at rated output), 240 W (EN60065), 21 W (no-signal) / DC: 14.6 A (at rated output), 0.4 A (no-signal) |
| Rated Output | 240 W |
| Input | 2 program inputs (parallel), 0 dB*, 20 kΩ, balanced / 2 priority inputs (parallel), 0 dB*, 20 kΩ, balanced |
| Impedance | 42 Ω (100 V) |
| S/N Ratio | 80 dB or more |
| Total Harmonic Distortion | 1 % or less (at rated output f = 1 kHz) |
| Frequency Response | 80 Hz - 16 kHz, ±3 dB (at 1/3 rated output) |
| Ventilation | Fan cooling |
| Operating Temperature | 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Panel: Aluminum, black, alumite |
| Dimensions | 483.6 (W) × 132.6 (H) × 337.8 (D) mm (19.04" × 5.22" × 13.3") |
| Weight | 13.4 kg (29.54 lb) |
| Accessory | Power cable (2 m (6.56 ft)) …1, Removable terminal plug (2 pins) …2, Removable terminal plug (3 pins) …2, Removable terminal plug (5 pins) …2, Fuse (4 A) …1 |
| Option | Fault detector: YA-1000A |
| Power Source | AC: 230 V AC, 50/60 Hz / DC: 24 V DC |
| Power Consumption | AC: 537 W (at rated output), 240 W (EN60065), 21 W (no-signal) / DC: 14.6 A (at rated output), 0.4 A (no-signal) |
| Rated Output | 240 W |
| Input | 2 program inputs (parallel), 0 dB*, 20 kΩ, balanced / 2 priority inputs (parallel), 0 dB*, 20 kΩ, balanced |
| Impedance | 42 Ω (100 V) |
| S/N Ratio | 80 dB or more |
| Total Harmonic Distortion | 1 % or less (at rated output f = 1 kHz) |
| Frequency Response | 80 Hz - 16 kHz, ±3 dB (at 1/3 rated output) |
| Ventilation | Fan cooling |
| Operating Temperature | 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Panel: Aluminum, black, alumite |
| Dimensions | 483.6 (W) × 132.6 (H) × 337.8 (D) mm (19.04" × 5.22" × 13.3") |
| Weight | 13.4 kg (29.54 lb) |
| Accessory | Power cable (2 m (6.56 ft)) …1, Removable terminal plug (2 pins) …2, Removable terminal plug (3 pins) …2, Removable terminal plug (5 pins) …2, Fuse (4 A) …1 |
| Option | Fault detector: YA-1000A |
