8 Ω, High impedance (100 V line): 330 Ω (30 W), 500 Ω (20 W), 670 Ω (15 W), 1 k Ω (10 W), and 2 k Ω (5 W), High impedance (70 V line): 170 Ω (30 W), 250 Ω (20 W), 330 Ω (15 W), 500 Ω (10 W), and 1 k Ω (5 W), Note: Impedance is changeable by means of the rotary switch.
Sound Pressure Level
90 dB (1 W, 1 m)
Frequency Response
80 - 20,000 Hz
Internal Speakers
Low frequencies: 12 cm dynamic speaker, High frequencies:2.5 cm dome tweeter
Operating Temperature Range
- 10°C to +50°C
Splash-Proof Capability
IP-X3 (when the angle is specified in vertical or horizontal installation)
8 Ω, High impedance (100 V line): 330 Ω (30 W), 500 Ω (20 W), 670 Ω (15 W), 1 k Ω (10 W), and 2 k Ω (5 W), High impedance (70 V line): 170 Ω (30 W), 250 Ω (20 W), 330 Ω (15 W), 500 Ω (10 W), and 1 k Ω (5 W), Note: Impedance is changeable by means of the rotary switch.
Sound Pressure Level
90 dB (1 W, 1 m)
Frequency Response
80 - 20,000 Hz
Internal Speakers
Low frequencies: 12 cm dynamic speaker, High frequencies:2.5 cm dome tweeter
Operating Temperature Range
- 10°C to +50°C
Splash-Proof Capability
IP-X3 (when the angle is specified in vertical or horizontal installation)
