| Image Sensor |
IMX327 |
| Main processor |
Hi3516C |
| Resolution |
2MP 1080P |
| Effective Pixels |
1945(H)*1097(V) |
| Compression |
H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG |
| TV System |
PAL/NTSC |
| Electronic Shutter Time |
Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec |
| S/N Ratio |
≥52dB |
| Scanning System |
Progressive |
| Video Output |
Network |
| Reset Button |
Optional |
| Focus Length |
Board Lens 3.6mm |
| Focus Control |
Fixed |
| Lens Type |
Fixed |
| Pixels |
3M |
| Infrared LED |
14µ x 18PCS |
| Infrared Distance |
20M |
| IR Status |
Auto Control |
| IR Power On |
Auto Control |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP |
| ONVIF |
Support ONVIF 2.4 |
| P2P |
YES, Support QR Code |
| POE |
Optional, Support IEEE 802.3af |
| Video Delay |
0.3S (Within the Lan) |
| Main Stream 1 |
2048*1536@15fps |
| Main Stream 2 |
1920*1080@30fps |
| Main Stream 3 |
1280*720@30fps |
| Sub Stream 1 |
720*480@15fps 720*480@30fps |
| Sub Stream 2 and 3 |
/ |
| Tri Stream |
352*288@15fps 352*288@30fps |
| IE Brower |
IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53), Mac Safari |
| Smart Phone |
iPhone, iPad, Android, Android Pad |
| Day/Night |
Color/ B&W (IR-CUT ) |
| Image Config |
Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering |
| Full Starlight |
/ |
| Corridor Pattern |
Support |
| Defog Mode |
Support |
| ROI |
Support |
| BLC |
Support |
| HDR |
/ |
| WDR |
Supprot |
| Motion Detection |
Support |
| Privacy Masking |
3 Rectangular Zone |
| Recording Mode |
NVR/NAS/CMS/Web |
| Language |
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French,Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands |
| Audio |
/ |
| Alarm |
/ |
| SD Card Slot |
Optional, Support Max 128GB |
| RS485 |
/ |
| Housing |
IP66 |
| Anti-cut Bracket |
NO |
| IR Cut Filter |
YES |
| Operation Temperature |
-20℃ ~ +60℃ RH95% Max |
| Storage Temperature |
-20℃ ~ +60℃ RH95% Max |
| Power Source |
DC12V±10%,850mA |
| Dimension |
￠93 x 74(H) mm |
| Weight |
400g |
