| Image Sensor |
1/2.9" Progressive Scan CMOS Sensor |
| Resolution |
2MP 1080P |
| Effective Pixels |
1920(H)*1080(V) |
| Compression |
H.264/H.265/JPEG/AVI/MJPEG |
| TV System |
PAL/NTSC |
| Electronic Shutter Time |
Auto: PAL 1/25-1/10000Sec; NTSC 1/30-1/10000Sec |
| Minimun Illumination |
0.01Lux |
| S/N Ratio |
60dB |
| Scanning System |
Progressive |
| Video Output |
Network |
| Reset Button |
Optional |
| Focus Length |
3.6mm |
| Focus Control |
Fixed |
| Lens Type |
Fixed |
| Pixels |
2MP |
| Infrared LED |
14µ x 20PCS |
| Infrared Distance |
25M |
| IR Status |
Auto Control |
| IR Power On |
Smart, Manual & Timed mode |
| Ethernet |
RJ-45 (10/100Base-T) |
| Wireless |
/ |
| Protocol |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP, UDP |
| ONVIF |
Support ONVIF 19.12(Profile S/T/G) |
| P2P |
YES |
| POE |
Optional, Support IEEE 802.3af |
| Video Delay |
0.3S (Within the Lan) |
| Main Stream 1 |
1920*1080@30fps |
| Main Stream 2 |
1280*720@30fps |
| Main Stream 3 |
/ |
| Sub Stream 1 |
720*480@30fps |
| Sub Stream 2 |
352*288@30fps |
| Sub Stream 3 |
/ |
| Tri Stream |
/ |
| IE Brower |
IE8-11, Google Chrome, Firefox |
| Smart Phone |
iPhone, Android |
| Intelligent Analysis |
Intrusion Detetion,motion detection based on human detection |
| Day/Night |
Color/ B&W (IR-CUT ) |
| Image Config |
Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control) |
| Full Color |
/ |
| Corridor Pattern |
/ |
| Defog Mode |
Support |
| ROI |
/ |
| BLC |
Support |
| WDR |
DWDR: 50dB |
| Motion Detection |
Support(support enable the detection based on human movement only) |
| Privacy Masking |
3 Rectangular Zone |
| Recording Mode |
NVR/CMS/Web |
| Language |
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands,Czech, Vietnamese |
| Audio |
Optional Audio In/Out/ Optional Audio In |
| Alarm |
/ |
| SD Card Slot |
/ |
| RS485 |
/ |
| Housing |
IP67 |
| Anti-cut Bracket |
YES |
| IR Cut Filter |
YES |
| Operation Temperature |
-20℃ ~ +60℃ RH95% Max |
| Storage Temperature |
-20℃ ~ +60℃ RH95% Max |
| Power Source |
DC12V±10%,900mA |
| Dimension |
157(W) x 70(H) x 66(D)mm |
| Weight |
650g |
