| Facial Detection And Analytics |
Face picture comparison, human face capture, face picture search |
| Face Picture Library |
Up to 32 face picture libraries, with up to 100,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 20 GB) |
| Facial Detection And Analytics Performance |
8-ch 8 MP human face capture (HD network camera, up to 8 MP, H.264/H.265) |
| Face Picture Comparison |
16-ch face picture comparison alarm |
| Human/Vehicle Analysis |
Up to 16-ch 4 MP (HD network camera, up to 8 MP, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm |
| Structured Analysis |
Up to 8-ch 2 MP (HD network camera, up to 8 MP, H.264/H.265) live video structuralization analysis |
| Face Picture Library |
Up to 32 face picture libraries, with up to 100,000 face pictures in total |
| Face Picture Comparison |
8-ch face picture comparison alarm |
| IP Video Input |
32-ch Up to 12 MP resolution *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. |
| Incoming Bandwidth |
320 Mbps |
| Outgoing Bandwidth |
256 Mbps |
| Incoming Bandwidth (RAID Mode) |
200 Mbps |
| Outgoing Bandwidth (RAID Mode) |
200 Mbps |
| HDMI 1 Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI 2 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA 1 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA 2 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video Output Mode |
HDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output |
| CVBS Output |
N/A |
| Audio Output |
2-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| Decoding Format |
H.265/H.265+/H.264/H.264+/MPEG4 |
| Decoding Capability |
1-ch@32 MP (30 fps)/16-ch@1080p (30 fps) |
| Synchronous Playback |
16-ch |
| Recording Resolution |
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF /2CIF/CIF/ *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. |
| Stream Type |
Video, Video & Audio |
| Dual-Stream |
Support |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/MP2L2 |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Remote Connection |
128 |
| Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| RAID Type |
RAID0, RAID1, RAID5, RAID6, RAID10 |
| SATA |
8 SATA interfaces |
| ESATA |
1 eSATA interface |
| Capacity |
Up to 10 TB capacity for each HDD |
| Serial Interface |
RS-232; RS-485; Keyboard |
| USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm In/Out |
16/8 |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Consumption |
≤ 70 W |
| Working Temperature |
-10 to +55° C (+14 to +131° F) |
| Working Humidity |
10 to 90% |
| Dimension (W × D × H) |
445 × 465 × 92 mm (17.5"× 18.3" × 3.6") |
| Weight |
≤ 10 kg (22 lb) |
| Obtained Certification |
CE, FCC, UL, CB, WEEE, BIS, IC, RCM, KC, LOA |
| FCC |
Part 15 Subpart B, ANSI C63.4 |
| CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4，EN 55035:2017 |
