| Human/Vehicle Analysis |
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; |
| Perimeter Protection |
Human/Vehicle Analysis: Up to 8-ch, for channel 1/2/3/4/17/18/19/20 only |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution |
When 1080p Lite mode is not enabled: 4 MP Lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF |
| Frame Rate |
Main stream: When 1080p Lite mode is not enabled: For 4 MP stream access: 4 MP Lite@15 fps; 1080p Lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When 1080p Lite mode is enabled: 4 MP Lite@15 fps; 1080p Lite/720p Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) Sub-stream: WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N) |
| Video Bitrate |
32 Kbps to 6 Mbps |
| Dual-Stream |
Support |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| IP Video Input |
16-ch (up to 48-ch); Up to 6 MP resolution; Support H.265+/H.265/H.264+/H.264 IP cameras |
| Analog Video Input |
32-ch; BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| Incoming Bandwidth |
200 Mbps |
| Outgoing Bandwidth |
160 Mbps |
| HDTVI Input |
4 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 |
| AHD Input |
4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| CVBS Input |
PAL/NTSC |
| HDCVI Input |
1080p25, 1080p30, 720p25, 720p30 |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI 1 Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI 2 Output |
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Video Output Mode |
HDMI1/VGA simultaneous output, HDMI2/VGA independent output |
| Audio Input |
16-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output |
2-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
| Synchronous Playback |
16-ch |
| Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, SNMP |
| Remote Connection |
128 |
| Network Interface |
2, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| SATA |
8 SATA interfaces |
| ESATA |
Support |
| Capacity |
Up to 12 TB capacity for each disk |
| Serial Interface |
RS-232, RS-485 (full-duplex), Keyboard |
| USB Interface |
Front panel: 2 × USB 2.0, Rear panel: 1 × USB 3.0, |
| Alarm In/Out |
16/8 |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Consumption |
≤ 40 W (without HDD) |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
445 × 465 × 88 mm (17.5 × 18.3 × 3.5 inch) |
| Weight |
≤ 10 kg (without HDD, 22.0 lb.) |
