| Human/Vehicle Analysis |
Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; |
| Perimeter Protection |
Human/Vehicle Analysis: Up to 4-ch |
| Facial Detection And Capture |
Face picture detection, face picture search |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution |
8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Frame Rate |
Main stream:
8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps;
1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N);
Sub-stream:
WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
| Video Bitrate |
32 Kbps to 10 Mbps |
| Dual-Stream |
Support |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| IP Video Input |
4-ch (up to 12-ch); Up to 8 MP resolution; Enhanced IP mode on: 8-ch (up to 16-ch), each up to 4 Mbps;Support H.265+/H.265/H.264+/H.264 IP cameras |
| Analog Video Input |
8-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDMI Output |
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| CVBS Input |
PAL/NTSC |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Synchronous Playback |
8-ch |
| HDTVI Input |
8 MP(3840 × 2160)@15 fps, 8 MP(3840 × 2160)@12 fps, 3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 5 MP(2560 × 1944)@12 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 3 MP@18 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps |
| AHD Input |
5 MP(2560 × 1944)@20 fps, 5 MP(2560 × 1944)@12 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps |
| VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| HDCVI Input |
8 MP(3840 × 2160)@15 fps, 8 MP(3840 × 2160)@12 fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Audio Input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Total Bandwidth |
128Mbps |
| Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Remote Connection |
64 |
| Network Interface |
1,RJ45 10M/100M/1000M self-adaptive |
| SATA |
1 SATA interface |
| Capacity |
Up to 10 TB capacity for each disk |
| Serial Interface |
RS-485 (half-duplex) |
| USB Interface |
1 × USB 2.0；1 × USB 3.0 |
| Alarm In/Out |
N/A |
| Power Supply |
12 VDC |
| Consumption |
≤ 10 W |
| Working Temperature |
-10 °C to +55 °C (+14 °F to +131 °F) |
| Working Humidity |
10% to 90% |
Dimension
(W × D × H) |
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Weight |
≤ 2 kg (4.4 lb) |
