| Intelligent Analytics |
AI By NVR, AI By Camera Engine |
| Facial Detection And Analytics |
Face picture comparison, human face capture, face picture search |
| Face Picture Library |
Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150MB) |
| Face Picture Comparison (Captured From Camera) |
4-ch face picture comparison alarm |
| Facial Detection And Analytics Performance |
1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265) |
| Motion Detection 2.0 |
By NVR: 16-ch |
| Perimeter Protection |
By NVR: 4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total |
| IP Video Input |
16-ch, Up to 12 MP resolution, *: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. |
| Incoming Bandwidth |
160 Mbps |
| Outgoing Bandwidth |
256 Mbps |
| HDMI 1 Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output |
| HDMI 2 Output |
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output |
| VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Decoding Format |
H.265+/H.265/H.264+/H.264/MPEG4 |
| Recording Resolution |
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF,
*: 32 MP and 24 MP is only available for channel 1 when ultra HD resolution mode is enabled. |
| Synchronous Playback |
16-ch |
| Live View Window Division |
1/2/4/6/8/9/16 |
| Aux Port Window Division |
1/2/4/6/8/9/16 |
| Decoding Capability |
16-ch @ 1080p (30 fps) |
| Dual-Stream Recording |
Support |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/MP2L2 |
| Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Remote Connection |
128 |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| API |
Compatible Browser |
| Serial Interface |
RS-485 (half-duplex), RS-232, Keyboard |
| SATA |
4 SATA interfaces supporting hot-plug |
| Capacity |
Up to 10 TB capacity for each disk |
| ESATA |
1 eSATA interface |
| Alarm In/Out |
16/4 |
| USB Interface |
Front panel: 2 × USB 2.0;
Rear panel: 1 × USB 3.0 |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Consumption |
≤ 30 W (without HDD) |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Chassis |
19-inch rack-mounted 1.5U chassis |
| Dimension (W × D × H) |
445 × 400 ×75 mm ( 17.5"× 15.7" × 3.0") |
| Weight |
≤ 5.6 kg (without HDD, 12.3 lb.) |
| Certification CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
