Hikvision DS7716NXI-I4/16P/4S NVR

http://www.techcore.com.ph/web/image/product.template/54/image_1920?unique=f964094

• Up to 16 channel IP cameras can be connected
• Supports decoding H.265+/H.265/H.264+/H.264 video formats
• Up to 12 MP high-definition live view, storage and playback
• Up to 12-ch @ 1080p decoding capacity
• Up to 256 Mbps high incoming bandwidth ensures IP cameras can be connected
• 2 HDMI and 1 VGA interfaces: HDMI interfaces support independent video output
• 4 HDDs can be used for continuous video recording
• Compatible with third-party network cameras
• 4-ch false alarm reduction through human and vehicle target classification based on deep learning

This combination does not exist.

Contact Us
NVR Pro Series



Product Specification


Human/Vehicle Analysis False alarm filtering for 4-ch behavior (line crossing and intrusion) detection for 2 MP, 3 MP, and 4 MP network camera
IP Video Input 16-ch
HDMI Output 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz,
1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,
4K resolution is only available for HDMI.,
VGA Output HDMI,VGA
CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Incoming Bandwidth 256 Mbps/200 Mbps
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding Format H.265+,H.265,H.264+,H.264
Decoding Capability 12-ch@1080p
Synchronous Playback 16-ch
Recording Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/,DCIF/2CIF/CIF/QCIF,
Network Interface 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Interface 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power ≤ 200W
Standard IEEE 802.3 af/at
RAID Type No
SATA 4
ESATA 1 eSATA interface
Capacity Up to 8 TB capacity for each HDD
Serial Interface RS-485 (half-duplex), RS-232, Keyboard
USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out 16/4
Power Supply 100 to 240 VAC,≤ 300 W
Consumption ≤ 30 W
Working Temperature -10° C to +55° C (+14° F to +131° F)
Working Humidity 10 to 90 %
Chassis 1.5U chassis
Dimension (W × D × H) 445 × 400 ×71 mm ( 17.5"× 15.7" × 2.8")
Weight ≤ 5 kg (11 lb)



Download Center


Datasheet

Quick Start Guide

User Manual
