| IP Video Input: |
16-ch |
| HDMI Output: |
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz |
| VGA Output: |
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| Video Output Mode: |
HDMI/VGA simultaneous output |
| Incoming Bandwidth: |
160 Mbps |
| Outgoing Bandwidth: |
80 Mbps |
| Audio Output: |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio: |
1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| Decoding Format: |
H.265+,H.265,H.264+,H.264 |
| Decoding Capability: |
1-ch@8 MP (30 fps)/5-ch@1080p (30 fps) |
| Synchronous Playback: |
16-ch |
| Recording Resolution: |
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| Network Protocol: |
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Network Interface: |
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| PoE Interface: |
16-ch;16, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power: |
≤ 150W |
| Standard: |
IEEE 802.3 af/at |
| RAID Type: |
No |
| SATA: |
2 SATA interfaces |
| Capacity: |
Up to 8TB capacity for each disk |
| USB Interface: |
2 × USB 2.0 |
| Power Supply: |
100-240V～, 50/60Hz, 3.2A MAX |
| Consumption: |
≤ 15W |
| Working Temperature: |
-10 to +55º C (+14 to +131º F) |
| Working Humidity: |
10 to 90 % |
| Chassis: |
1U chassis |
| Dimension (W × D × H): |
385 × 315 × 52 mm (15.2"× 12.4" × 2.0") |
| Weight: |
≤ 2.6 kg (5.7 lb) |
