| IP Video Input |
8-ch |
| Incoming Bandwidth |
80 Mbps |
| Outgoing Bandwidth |
160 Mbps |
| HDMI Output |
4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| VGA Output |
1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| Video Output Mode |
HDMI/VGA independent output |
| Audio Input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1kΩ, using the audio input) |
| Decoding Format |
H.265/H.265+/H.264/H.264+ |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback |
8-ch |
| Decoding Capability |
1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726 |
| Remote Connection |
128-ch |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network Interface |
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| PoE Interface |
8, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power |
≤ 120 W |
| Standard |
IEEE 802.3 af/at |
| SATA |
2 SATA interfaces |
| Capacity |
Up to 10 TB capacity for each HDD |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| Alarm In/Out |
4/1 |
| Power Supply |
48VDC，2.5A |
| Consumption |
≤ 15 W (without HDD and PoE off) |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10 to 90 % |
| Dimension (W × D × H) |
380 × 317 × 51.5 mm (15.0" × 12.5" × 2.0") |
| Weight |
≤ 3 kg (without HDD, 6.6 lb.) |
| Certification |
FCC: Part 15 Subpart B, ANSI C63.4-2014; CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
