| Motion Detection 2.0 |
Human/Vehicle Analysis: 1-ch;4-ch |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726 |
| IP Video Input |
4-ch |
| Incoming Bandwidth |
40 Mbps |
| Outgoing Bandwidth |
80 Mbps |
| HDMI Output |
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz |
| VGA Output |
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
| Video Output Mode |
HDMI/VGA simultaneous output |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Decoding Format |
H.265+/H.265/H.264+/H.264 |
| Recording Resolution |
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback |
4-ch |
| Decoding Capability |
1-ch@8 MP (30 fps)/5-ch@1080p (30 fps) |
| Remote Connection |
32 |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network Interface |
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface |
| SATA |
1 SATA interface |
| Capacity |
Up to 8 TB capacity for each disk |
| USB Interface |
2 × USB 2.0 |
| Alarm In/Out |
N/A (4/1 is optional) |
| Power Supply |
12 VDC, 1.5 A |
| Consumption |
≤ 10 W (without HDD) |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
320 × 240 × 48 mm (12.4" × 9.4" × 1.9") |
| Weight |
≤ 1 kg (without HDD, 2.2 lb.) |
| Certification |
FCC: Part 15 Subpart B, ANSI C63.4-2014; CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
