Hikvision DS-7708NI-I4 NVR

Hikvision DS-7708NI-I4 NVR

• Up to 8 channel IP cameras can be connected
• Up to 1-ch@32 MP/2-ch@12 MP/16-ch@1080p decoding capacity
• 1 HDMI and 1 VGA interfaces: both interfaces support independent video output
• 4 HDDs for continuous video recording
• Supports various special function cameras, including thermal camera /fisheye/people counting/heatmap/ANPR (automatic number plate recognition)
• Advanced streaming technology enables smooth live view and data self-correction in poor network conditions
• Supports dual-stream recording to save time and bandwidth

NVR Pro Series
0.00 ₱ 0.00 ₱

Add to cart
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
Contact Us

Product Specification


IP Video Input 8-ch Up to 12 MP resolution
Incoming Bandwidth 80 Mbps
Outgoing Bandwidth 256 Mbps
HDMI 1 Output 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI 2 Output 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
VGA Output 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Video Output Mode HDMI1/VGA simultaneous output, HDMI2/VGA independent output
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding Format H.265/H.265+/H.264/H.264+
Decoding Capability 2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
Synchronous Playback 8-ch
Recording Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
Stream Type Video, Video & Audio
Audio Compression G.711ulaw/G.711alaw/G.722/G.726
Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Remote Connection 32
Network Interface 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
SATA 4 SATA interfaces
ESATA 1 eSATA interface
Capacity Up to 10 TB capacity for each HDD
Serial Interface 1 RS-485 (half-duplex), 1 RS-232
USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out 16/4
Ctrl 12V Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.; *: The Ctrl 12V power is controlled by alarm output 9.
DC 12V 12 VDC, 1 A power output
Power Supply 100 to 240 VAC, 50 to 60 Hz
Consumption ≤ 20 W (without HDD)
Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity 10% to 90%
Dimension (W × D × H) 445 × 400 ×71 mm ( 17.5"× 15.7" × 2.8")
Weight ≤ 5 kg (without HDD, 11 lb.)
Certification CE: EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Obtained Certification CE, CB, UKCA, IC
