| Video Compression |
H.264+/H.264 |
| Encoding Resolution |
When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF,When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF |
| Frame Rate |
Main stream: ,When 1080p Lite mode not enabled:,For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),When 1080p Lite mode enabled:,1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N), |
| Video Bit Rate |
32 Kbps to 4 Mbps |
| Dual Stream |
Support |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711u |
| Audio Bit Rate |
64 Kbps |
| IP Video Input |
1-ch (up to 5-ch) Up to 960p resolution Support H.264+/H.264 IP cameras |
| Analog Video Input |
4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| Turbo HD Input |
1080p25, 1080p30, 720p25, 720p30 |
| AHD Input |
1080p25, 1080p30, 720p25, 720p30 |
| HDCVI Input |
1080p25, 1080p30, 720p25, 720p30 |
| CVBS Input |
Support |
| Audio Input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
Reuse the first audio input |
| Synchronous Playback |
4-ch |
| VGA/HDMI Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Remote Connections |
32 |
| Network Protocols |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Network Interface |
1, RJ45 10M/100M self-adaptive Ethernet interface |
| SATA |
1 SATA interface |
| Capacity |
Up to 6 TB capacity for each disk |
| Alarm In/Out |
N/A |
| USB Interface |
Rear panel: 2 × USB 2.0 |
| Power Supply |
12 VDC |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Weights (Without HDD) |
≤ 1 kg (2.2 lb) |
| Consumption(Without HDD) |
≤ 8 W |
| Dimensions(W × D × H) |
260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch) |
