| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Max. Resolution |
1920 × 1080 |
| Min. Illumination |
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter with auto switch |
| Angle Adjustment |
Pan: 0° to 355°; Tilt: -10° to 90° |
| Lens Type |
Fixed Lens |
| Focal Length & FOV |
2.8 mm, horizontal field of view 105.8° |
| Lens Mount |
M12 |
| Aperture |
F2.0 |
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 5 meters |
| Main Stream |
50 Hz: 25 fps (1920 × 1080, 1280 ×720),60Hz: 30fps (1920 × 1080, 1280 ×720) |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 352 × 288, 640 × 480, 320 × 240),60 Hz: 30 fps (704 × 480, 352 × 240, 640 × 480, 320 × 240) |
| Video Bit Rate |
32 Kbps – 8 Mbps |
| Video Compression |
Main stream: H.264,Sub stream: H.264 |
| H.264 Type |
Baseline Profile/Main Profile |
| Region Of Interest (ROI) |
Support 1 fixed region for each stream |
| Audio Type |
Support mono soundtrack |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2) |
| Audio Sampling Rate |
Max. 16 kHz |
| Environment Noise Filtering |
Support |
| Network Storage |
Support Micro SD/SDHC/SDXC card, up to 128 GB local storage |
| Encryption Mode |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Wi-Fi Protocol |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
| Frequency Range |
2.4 GHz - 2.4835 GHz |
| Channel Bandwidth |
20/40 MHz Support |
| Transfer Rate |
11b: 11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps |
| Wireless Range |
50 meters (The performance varies based on actual environment) |
| Image Settings |
Brightness, saturation, sharpness, contrast are adjustable via client software |
| Day/Night Switch |
Support auto/scheduled |
| Wide Dynamic Range (WDR) |
Digital WDR |
| Image Enhancement |
BLC，3D DNR |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| Audio |
Support mono soundtrack, 1 build-in microphone, 1 build-in speaker |
| Reset Key |
Yes |
| Basic Event |
Motion Detection，Video Tampering Alarm, excepetion(HDD Full, HDD Error, Network Disconnected, IP Address Conflicted, Illegal Login) |
| Power |
DC 5V ± 10 %，Max. 1.4 A, Max. 7 W，micro USB interface |
| Material |
Plastic |
| Dimension |
Φ 82.4 × 113.6 mm (Φ 3.25'' × 4.47'') |
| Weight |
Approx. 510 g (1.12 lb) |
| Startup And Operating Conditions |
-10 °C to 40 °C (14 °F to 104 °F), Humidity 95% or less (non-condensing) |
| General Function |
One-key reset, Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark |
