| Image Sensor |
2 MP CMOS |
| Max. Resolution |
1920 (H) × 1080 (V) |
| Min. Illumination |
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light ON |
| Shutter Time |
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Day & Night |
24/7 Color Imaging |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Signal System |
PAL/NTSC |
| Slow Shutter |
Max. 16 times |
| Light Alarm |
Solid Light Alarm (White Light) |
| Lens Type |
2.8 mm, 3.6 mm, 6 mm fixed focal lens |
| Focal Length & FOV |
2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116° 3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91° 6 mm, horizontal FOV: 51°, vertical FOV: 28°, diagonal FOV: 59° |
| Lens Mount |
M12 |
| Supplement Light Type |
White Light |
| Supplement Light Range |
Up to 20 m |
| Smart Supplement Light |
Yes |
| Image Parameters Switch |
STD/HIGH-SAT/HIGHLIGHT |
| Image Settings |
Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, AGC |
| Frame Rate |
TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
| Day/Night Mode |
Color |
| Wide Dynamic Range (WDR) |
≥130 dB |
| Image Enhancement |
WDR, BLC, HLC, Global, HLS |
| Privacy Mask |
4 programmable privacy masks |
| Noise Reduction |
3D DNR/2D DNR |
| White Balance |
Auto/Manual |
| Video Output |
Switchable TVI/AHD/CVI/CVBS |
| Motion Detection |
4 programmable motion areas |
| Material |
Plastic |
| Dimension |
Φ 85.02 mm × 81.25 mm (Φ 3.35" × 3.2") |
| Weight |
Approx. 163 g (0.36 lb.) |
| Operating Condition |
-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Communication |
HIKVISION-C |
| Language |
English |
| Power |
12 VDC ± 25%, Max. 2.9 W *You are recommended to use one power adapter to supply the power for one camera. |
