| Image Sensor |
5 megapixel progressive scan CMOS |
| Max. Resolution |
2560 (H) × 1944 (V) |
| Min. Illumination |
Color: 0.003 Lux@(F1.6, AGC ON), 0 Lux with IR |
| Shutter Time |
PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360° |
| Signal System |
PAL/NTSC |
| Lens Type |
3.6 mm, 6 mm, 8 mm, 12 mm fixed lens |
| Focal Length & FOV |
78° (3.6 mm), 48° (6 mm), 37° (8 mm), 23° (12 mm) |
| Lens Mount |
M12 |
| Image Settings |
Brightness, Sharpness, 3D DNR, Mirror, Smart IR |
| Frame Rate |
TVI: 2 MP@25fps, 2 MP@30fps, 4 MP@25fps, 4 MP@30fps, 5 MP@20fps; AHD: 4 MP@25fps, 4 MP@30fps, 5 MP@20fps; CVI: 4 MP@25fps, 4 MP@30fps; CVBS: PAL, NTSC |
| Day/Night Mode |
Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) |
≥ 130 dB |
| Image Enhancement |
BLC |
| Privacy Mask |
4 programmable privacy masks |
| Noise Reduction |
Level 1 to 9 |
| White Balance |
Auto/Manual |
| AGC |
Yes |
| Video Output |
1 HD analog output, TVI/AHD/CVI/CVBS |
| Event |
Motion Detection: 4 programmable areas |
| Material |
Metal |
| Dimension |
81.9 mm × 86.7 mm × 217.9 mm (3.22" × 3.41" × 8.58") |
| Weight |
Approx. 570 g (1.26 lb.) |
| Operating Condition |
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing) |
| Communication |
Up the coax, Protocol: HIKVISION-C (TVI output) |
| Language |
English |
| Power Supply |
12 VDC ± 25 *You are recommended to use one power adapter to supply the power for one camera. |
| Consumption |
Max.6.6 W |
| IR Range |
Up to 80 m |
| Approval |
Protection: 1P67 |
