| Image Sensor |
1/2.9" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Day & Night |
IR Cut Filter |
| Wide Dynamic Range |
120dB |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 355° |
| DNR |
3D DNR |
| Lens |
2.8 to 12 mm;Motorized |
| Auto-Iris |
No |
| Aperture |
F1.6 |
| Focus |
Auto |
| FOV |
Horizontal field of view: 88° to 27°,Vertical field of view: 56° to 18°,Diagonal field of view: 110° to 33° |
| Lens Mount |
Φ14 |
| Illuminator |
IR |
| Range |
Up to 50 m |
| Wavelength |
850nm |
| Max. Resolution |
3072 × 2048 |
| Main Stream |
50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720),
60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288),
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Video Compression |
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
| H.264 Type |
Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| SVC |
H.264 and H.265 encoding support |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8kHz/16kHz/32kHz/44.1kHZ/48kHz |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by Alarm In |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Simultaneous Live View |
Up to 6 channels |
| User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
| Client |
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
| Alarm Trigger |
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Audio |
1 input (line in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound |
| Alarm |
1 input, 1 output (max. 12 VDC, 30 mA), terminal block |
| Video Output |
1Vp-p composite output (75 Ω) (For adjustment only) |
| On-Board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Impact Protection |
IK10 |
| Compression Standard |
H.264+ |
| Main stream supports |
H.265+ |
| General Function |
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening |
| Reset |
Yes |
| Startup And Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3at, class 4), Φ 5.5 mm coaxial power plug |
| Power Consumption And Current |
12 VDC, 1.2A, max. 14.5W,PoE (802.3at, 42.5V to 57V), 0.5A to 0.3A, max. 18W |
| Material |
Metal |
| Dimensions |
Φ144.1 × 332.7 mm (Φ5.7" × 13.1") |
| Weight |
Camera: 1893 g (4.2 lb.) |
| Interface Protection |
IP66 |
