| Image Sensor |
1/3" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Focus |
Auto |
| Lens Type |
2.8 to 12 mm，Motorized |
| FOV |
horizontal FOV: 104° to 29°,vertical FOV: 55° to 17°,diagonal FOV: 125° to 34° |
| Aperture |
F1.6 |
| Lens Mount |
Φ14 |
| Aperture Type |
Fixed |
| IR Range |
Up to 50 m |
| Wavelength |
850nm |
| Video |
Max. Resolution 2688 × 1520 |
| Main Stream |
50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720); 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288),60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Video Compression |
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Main Profile/High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Main stream supports |
| H.265+ |
Main stream supports |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate |
4Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
| Network Storage |
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Client |
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 |
| Web Browser |
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view: Chrome 45.0+, Firefox 52.0+ Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by alarm in |
| DNR |
3D DNR |
| Image Enhancement |
BLC/3D DNR/HLC |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event |
Line crossing detection, intrusion detection, face detection |
| Face Detection |
Yes |
| Audio |
1 input (line in/mic.in, 3.5 mm), 1 output (line out, 3.5 mm), mono sound |
| Alarm |
1 input, 1 output (max. 12 VDC, 30 mA), terminal block |
| On-Board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Video Output |
1 Vp-p composite output(75Ω) (For adjustment only) |
| Linkage Method |
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email |
| General Function |
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Startup And Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, terminal block,PoE (802.3at, class 4) |
| Power Consumption And Current |
12 VDC, 1.2A, max. 14.5W,PoE (802.3at, 42.5V to 57V), 0.43A to 0.3A, max. 18W |
| Camera Dimension |
Φ 144.13 × 332.73 mm (Φ 5.7" × 13.1") |
| Camera Weight |
Camera: Approx. 1740 g (3.8 lb.),With Package: Approx. 2610 g (5.8 lb.) |
