| Image Sensor |
1/3″ Progressive Scan CMOS |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux witd IR on |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Focal Length & FOV |
2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122°; 4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 100°;
6 mm, horizontal FOV 52°, vertical FOV 28°, diagonal FOV 61° |
| Lens Type |
Fixed focal lens, 2.8, 4, and 6 mm optional |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| Iris Type |
Fixed |
| DORI |
2.8 mm: D: 67 m, O: 26 m, R: 13 m, I: 6 m;
4 mm: D: 80 m, O: 31 m, R: 16 m, I: 8 m; 6 mm: D: 120 m, O: 47,m, R: 24,m, I: 12 m |
| Supplement Light Range |
Up to 40 m |
| Supplement Light Type |
IR |
| IR Wavelengtd |
850 nm |
| Smart Supplement Light |
Yes |
| Main Stream |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720);
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360);
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265/H.264/H.264+/H.265+;
Sub-stream: H.265/H.264/MJPEG;
Third stream: H.265/H.264 |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region Of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Audio Compression |
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate |
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/16-64 Kbps(AAC-LC) |
| Audio Sampling Rate |
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
-U: Yes |
| Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest autdentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest autdentication for Open Network Video Interface |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE 10, IE 11;
Plug-in free live view : Chrome 57.0+, Firefox 52.0+; Local service: Chrome 57.0+, Firefox 52.0+ |
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) |
120 dB |
| Image Enhancement |
BLC, HLC, 3D DNR |
| SNR |
≥ 52 dB |
| Etdernet Interface |
1 RJ45 10 M/100 M self-adaptive Etdernet port |
| On-Board Storage |
Built-in memory card slot, support microSD card, up to 512 GB |
| Built-In Microphone |
-U: Yes |
| Reset Key |
Yes |
| Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event |
Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle)) |
| Linkage |
Upload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture |
| Power |
12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection;
PoE: 802.3af, Class 3, 36 V to 57 V), 0.2 A to 0.13 A, max. 7 W |
| Dimension |
Ø70 × 161.7 mm (Ø2.76″ × 6.37″) |
| Package Dimension |
216 mm × 121 mm × 118 mm (8.6" × 4.8" × 4.7") |
| Weight |
Approx. 490 g (1.1 lb.) |
| Witd Package Weight |
Approx. 724 g (1.6 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General Function |
Anti-flicker, heartbeat, password reset via e-mail, pixel counter |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Litduanian, Portuguese (Brazil), Ukrainian |
| Approval |
EMC:
FCC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015);
Safety:
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
Environment:
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006);
Protection:
IP67 (IEC 60529-2013) |
