| Image Sensor: |
1/3″ Progressive Scan CMOS |
| Signal System: |
PAL/NTSC |
| Min. Illumination: |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter time: |
1/3 s to 1/100,000 s |
| Slow shutter: |
Support |
| Lens: |
2.8 mm @ F1.6: horizontal FOV: 103°, vertical FOV: 58°, diagonal FOV: 123°
4 mm @F1.6: horizontal FOV: 83°, vertical FOV: 45°, diagonal FOV: 99°
6 mm @F1.6: horizontal FOV: 51°, vertical FOV: 29°, diagonal FOV: 58°
8 mm @F1.6: horizontal FOV: 39°, vertical FOV: 22°, diagonal FOV: 45° |
| Lens Mount: |
M12 |
| Adjustment Range: |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Day& Night: |
IR cut filter with auto switch |
| Wide Dynamic Range: |
120 dB |
| Digital noise reduction: |
3D DNR |
| Focus: |
Fixed |
| COMPRESSION STANDARD |
| Video Compression: |
H.265+/H.265/H.264+/H.264/MJPEG |
| Video bit rate: |
256Kbps~16Mbps |
| Triple Streams: |
Yes |
| IMAGE |
| Max. Image Resolution: |
2688 × 1520 |
| Frame Rate: |
50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080) |
| Sub Stream: |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream: |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Image Enhancement: |
BLC/3D DNR/ROI/HLC |
| Image Settings: |
Rotate mode, saturation, brightness, contrast, sharpness and white balance
adjustable by client software or web browser |
| Target Cropping: |
No |
| ROI: |
1 fixed region for main stream and sub-stream |
| Day/Night Switch: |
Day/Night/Auto/Schedule |
| NETWORK |
| Network Storage: |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger: |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
| System Compatibility: |
ONVIF (Profile S, Profile G),ISAPI |
| INTERFACE |
| Communication Interface: |
1 RJ45 10M / 100M Ethernet interface |
| On-board storage: |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
Yes |
| SMART FEATURE-SET |
| Behavior Analysis: |
Line crossing detection, intrusion detection |
| Line Crossing Detection: |
Cross a pre-defined virtual line |
| Intrusion Detection: |
Enter and loiter in a pre-defined virtual region |
| Recognition: |
Face Detection |
| GENERAL |
| Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: |
12 VDC, 0.5A, max. 6W
PoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 7.5W |
| Weather Proof: |
IP67 |
| IR Range: |
Up to 30m |
| Dimensions: |
Camera: Φ 70 × 155.03 mm (Φ 2.8″ × 6.1″)
Package: 216 × 121 × 118 mm (8.5″ × 4.8″ × 4.7″) |
| Weight: |
Camera: Approx. 420 g (0.9 lb.)
With Package: Approx. 700 g (1.5 lb.) |
