| Display |
3.5 inch Capacitive touch screen, resolution 480 x 320 |
| Network port |
10/100M auto adapt, RJ45 |
| AHD/CVI/TVI Camera test |
Support resolution 720p 25fps, 30fps, 50fps, 60fps / 1080P 25fps, 30fps, camera OSD menu control over coaxial cable (optional) |
| WIFI |
Built in WiFi, speeds 150M, display wireless camera image |
| IP camera |
ONVIF, COP, ACTi, Dahua, Hikvision, Samsung, Honeywell & etc. |
| Video input/output |
1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt) |
| Video Level Test |
Video signals measured in IRE or mV |
| Zoom Image |
Support Analog camera and IP camera image zoom /move |
| Snapshot, Video record and playback |
Image Screen snapshot, record, save, view and record and play back |
| 12V/1A power output |
Output DC12V/1A power for camera |
| Audio Test |
1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
| PTZ control |
Support RS232/RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc |
| Video Signal Generator |
Output one channel PAL/NTSC color bar video signal for testing monitor or video cable. (red, green ,blue, white and black color ) |
| Color bar generator |
Local side PC can login the tester, send the signal by network, test network connection communication whether normal |
| UTP Cable tester |
Test UTP cable connection status and display on the screen. Read the number on the screen |
| Data monitor |
Captures and analyzes the command data from controlling device, also can send hexadecimal |
| Network test |
IP address scan, link test, Ping test, Quickly search the connection IP camera and other device’s IP address |
| PoE test |
Measurement PoE switch or PSE power supply voltage and cable connection status |
| External power supply |
DC 5V(1.5A ) |
| Battery |
Built-in 3.7V Lithium polymer battery, 3500 mAh |
| Rechargeable |
After charging 3~4 hours, normal working time 8 hours |
| Operation setting |
Capacitive touch screen, OSD menu, Chinese/English |
| Auto Off |
1-30 (mins) |
| Working Temperature |
-10°C~+50°C |
| Working Humidity |
30%~90% |
| Dimension (WxHxD) |
194 x 112 x 48mm |
| Weight |
540g |
