| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Max. Resolution |
1920 × 1080 |
| Min. Illumination |
Color: 0.018 lux @ (F1.2, AGC ON),
B/W: 0.006 lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Lens Type |
Fixed focal lens, 4 , 6 , 8 , and 12 mm optional |
| Focal Length & FOV |
4 mm, horizontal FOV 83°, vertical FOV 43°, diagonal FOV 97°;
6 mm, horizontal FOV: 50°, vertical FOV 27°, diagonal FOV 59°;
8 mm, horizontal FOV 39°, vertical FOV 21°, diagonal FOV 45°;
12 mm, horizontal FOV 24°, vertical FOV 14°, diagonal FOV 28° |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| DORI |
4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m;
6 mm: D: 88.3 m, O: 35 m, R: 17.7 m, I: 8.8 m;
8 mm: D: 110.3 m, O: 43.8 m, R: 22.1 m, I: 11 m;
12 mm: D: 171 m, O: 67.9 m, R: 34.2 m, I: 17.1 m |
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240, 320 × 240) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60 Hz:
30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240) |
| Video Compression |
Main stream: H.265/H.264/H.265+/H.264+,
Sub stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline profile/main profile/high profile |
| H.265 Type |
Main profile |
| Region Of Interest (ROI) |
5 customized regions for each stream, and face dynamic tracking |
| Target Cropping |
Yes |
| Audio Type |
Mono sound |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/AAC/MP3 |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (Profile S, Profile G), PSIA, CGI, ISAPI |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE 8+, Chrome 41.0 to 44, Firefox 30.0 to 51, Safari 8.0 to 11,
Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+; Not recommended: Safari 11+, Edge |
| Image Settings |
Rotate mode, saturation, brightness, contrast, etc., adjustable by client software or web browser |
| Day/Night Switch |
Auto/Schedule/Alarm Trigger |
| Wide Dynamic Range (WDR) |
120 dB |
| Image Enhancement |
BLC/3D DNR |
| Privacy Mask |
8 programmable polygon privacy mask |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Audio |
1 line in, 1 line out |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. |
| Alarm |
1 alarm input, 1 alarm output |
| Basic Event |
Motion detection (support alarm triggered by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), Scene change detection, audio exception detection |
| Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture |
| Power |
100 VAC to 240 VAC, 0.15 A, 50/60 Hz, max. 7 W, terminal block, PoE: 802.3af, Class 3, 36 to 57 V, 0.3 to 0.2 A |
| Dimension |
202 mm × 174 mm × 172 mm (8.0"× 6.9" × 6.8") |
| Package Dimension |
435 mm × 255 mm × 285 mm (17.1" × 10" × 11.2") |
| Weight |
Approx. 6.17 kg (13.60 lb.) |
| With Package Weight |
Approx. 7.20 kg (15.87 lb.) |
| Storage Conditions |
-30 °C to +60 °C (-40 °F to +140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions |
-30°C to +60 °C (-22 °F to +140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Mirror, anti-flicker, heartbeat, watermark, password protection, privacy mask |
| Approval |
EMC:
FCC: FCC-SDoC (ANSI C63.4, FCC Part15 sub B);
CE: CE-EMC (EN 50130-4: 2011+A1: 2014, EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3:2013);
IC: IC-VoC (ICES-003 Issue 7: 2020);
KC: KN 301489-1, KN 301489-17, RRA NOTICE 2017-14 (2017.12.05), RRA NOTICE 2017-19 (2017.12.28);
Safety:
UL (UL 60950-1:2014, CAN/CSA C22.2 No. 60950-1-07: 2014);
CB (IEC 60950-1);
CE: CE-LVD (EN 60950-1: 2006+A11: 2009+A1: 2010+A12: 2011+A2: 2013);
Protection:
IK08 (IEC 62262:2002), IP68 (IEC 60529-2013);
Explosion-Proof Protection:
ATEX: II 2G Ex db IIC T6 Gb/ II 2D Ex tb IIIC T80°C Db IP68;
IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80°C Db IP68. |
| Notes |
For explosive gas atmospheres, the maximum surface temperature is 85°C;
For flammable dust atmospheres, the maximum surface temperature is 80°C;
IIC: for explosive gas atmospheres other than mines susceptible to firedamp;
For explosive gas mixture atmospheres: Zone 1, Zone 2, Zone 21, Zone 22. |
