| Image Sensor |
Vanadium Oxide Uncooled Focal Plane Arrays |
| Resolution |
160 × 120 |
| Pixel Pitch |
17 μm |
| Spectral Range |
8 μm to 14 μm |
| NETD |
< 40 mK (@ 25 °C, F# = 1.1) |
| Focal Length |
6.2 mm |
| IFOV |
2.74 mrad |
| Field Of View |
25.0° × 18.7° (H × V) |
| Min. Focusing Distance |
0.6 m |
| Aperture |
F1.1 |
| Digital Zoom |
× 2, × 4 |
| Image Sensor |
1/2.7" Progressive Scan CMOS |
| Resolution |
2688 × 1520 |
| Min. Illumination |
0.0089Lux @(F1.6,AGC ON) ,0 Lux with IR |
| Shutter Speed |
1 s to 1/100,000 s |
| Focal Length |
8 mm |
| Field Of View |
39.42° × 22.14°(H × V) |
| Aperture (Range) |
F1.6 |
| WDR |
120 dB |
| Target Coloration |
Yes. Supported in white hot and black hot mode. |
| IR Distance |
Up to 15 m |
| IR Intensity And Angle |
Automatically adjusted |
| White Light Range |
Up to 30 m |
| Visual Alarm |
Yes. White light alarm with adjustable flashing frequencies |
| Audio Alarm |
Yes, for two types of audible alarm (VCA, Temperature), 2 preset voice alerts (one for each), 6 importable user-defined voice alerts (4 options shared in the two types) |
| VCA |
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total. |
| Temperature Measurement |
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line) |
| Temperature Range |
- 20 °C to 150 °C (- 4 °F to 302 °F) |
| Temperature Accuracy |
± 8 °C (± 14.4 °F) |
| Main Stream |
Thermal: 25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240), Optical: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
Thermal: 25 fps (704 × 576, 352 × 288, 320 × 240) Optical: 50 Hz: 25 fps (704 × 576, 352 × 288) 60 Hz: 30 fps (704 × 480, 352 × 240) |
| Video Compression |
Main Stream: H.265/H.264, Sub-Stream: H.265/H.264/MJPEG |
| Audio Compression |
G.722.1/G.711ulaw/G.711alaw/MP2L2/G.726/PCM |
| Network Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE,SSL |
| Network Storage |
MicroSD/SDHC/SDXC card (up to 256 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| API |
ISAPI, HIKVISION SDK, third-party management platform,ONVIF |
| Simultaneous Live View |
Up to 20 channels |
| User/Host Level |
Up to 32 users, 3 levels: Administrator, Operator, User |
| Security |
User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
Live view (plug-in allowed) : Internet Explorer 11, Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +, Local service : Chrome 57.0 +, Firefox 52.0 + |
| Alarm Input |
1, alarm input (0-5 VDC) |
| Alarm Output |
1, alarm output (alarm response actions configurable) |
| Alarm Action |
SD recording/Relay output/Smart capture/FTP upload/Email linkage |
| Audio Input |
1, 3.5 mm Mic in/Line in interface, Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10% |
| Audio Output |
Linear level, impedance: 600 Ω |
| Communication Interface |
1, RJ45 10 M/100 M Self-adaptive Ethernet interface., 1, RS-485 interface (half duplex) |
| Web Client Language |
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Power Supply |
12 VDC ± 25%, φ 5.5 mm coaxial power plug, PoE (802.3af, class 3) |
| Power Consumption |
12 VDC ± 25%: 0.5 A, Max 6 W, PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, Max 6.5 W |
| Working Temperature/Humidity |
Temperature: - 40 °C to 65 °C (- 40 °F to 149 °F), Humidity: 95% or less |
| Protection Level |
IP67 Standard, TVS 6000V lightning protection, surge protection, voltage transient protection |
| Dimensions |
138.3 mm × 138.3 mm × 123.1 mm (5.45" × 5.45" × 4.85 ") |
| Weight |
940 g (2.07 lb) |
